Code release for Visual Chain-of-Thought Diffusion Models [Paper] [Blog]

Images sampled with VCDM.

Presented at CVPR 2023's Generative Models for Computer Vision workshop, ICML 2023 Workshop on Structured Probabilistic Inference & Generative Modeling

This repository is based on the code release for Elucidating the design space of diffusion-based generative models. Thank you to the authors for making this accessible.

Setting up

Python environment

We use Python 3.9.6, and can install the required packages in a fresh installation with:

pip install torch torchvision wandb tqdm matplotlib scikit-learn einops einops_exts git+https://github.com/openai/CLIP.git rotary-embedding-torch

Alternatively, see requirements.txt for a full specification of our requirements.

Environment variables for wandb logging

We log data from our training runs to Weights & Biases. To set up logging, we use the following environment variables.

export WANDB_ENTITY="<YOUR WANDB USERNAME>"
export WANDB_PROJECT="<NAME OF PROJECT TO LOG TO>"

Optionally, if you are running on compute nodes without an internet connection, you can use wandb offline to deactivate logging (and optionally sync the logs later with wandb sync).

Download datasets

We dowload AFHQ, FFHQ, and ImageNet following the instructions in the EDM repo. For convenience we copy and paste them below:

FFHQ: Download the Flickr-Faces-HQ dataset as 1024x1024 images and convert to ZIP archive at 64x64 resolution:

python dataset_tool.py --source=downloads/ffhq/images1024x1024 \
    --dest=datasets/ffhq-64x64.zip --resolution=64x64
python fid.py ref --data=datasets/ffhq-64x64.zip --dest=fid-refs/ffhq-64x64.npz

AFHQv2: Download the updated Animal Faces-HQ dataset (afhq-v2-dataset) and convert to ZIP archive at 64x64 resolution:

python dataset_tool.py --source=downloads/afhqv2 \
    --dest=datasets/afhqv2-64x64.zip --resolution=64x64
python fid.py ref --data=datasets/afhqv2-64x64.zip --dest=fid-refs/afhqv2-64x64.npz

ImageNet: Download the ImageNet Object Localization Challenge and convert to ZIP archive at 64x64 resolution:

python dataset_tool.py --source=downloads/imagenet/ILSVRC/Data/CLS-LOC/train \
    --dest=datasets/imagenet-64x64.zip --resolution=64x64 --transform=center-crop
python fid.py ref --data=datasets/imagenet-64x64.zip --dest=fid-refs/imagenet-64x64.npz

Example training commands

AFHQ from scratch:

Train model of CLIP embeddings (called auxiliary model in paper)

Run on 1 GPU:

torchrun --standalone --nproc_per_node=1 train.py --path=datasets/afhqv2-64x64.zip --data_class CLIPDataset --batch 256 --seed 1 --exist 0,1 --observed 0,0 --arch=dalle2 --lr=1e-4 --augment=0.15 --pred_x0 1

Train model of images given CLIP (called conditional image model in paper):

Run on 4 GPUs (see the torchrun documentation for help with parallel training):

torchrun --standalone --nproc_per_node=4 train.py --path=datasets/afhqv2-64x64.zip --data_class CLIPDataset --batch 128 --seed 1 --exist 1,1 --observed 0,1 --arch=ddpmpp --cres=1,2,2,2 --lr=1e-4 --dropout=0.05 --augment=0.15

FFHQ from pretrained

Downloading pretrained models

We use pretrained models from the EDM repo. To initialize FFHQ from a pretrained model, we specifically download https://nvlabs-fi-cdn.nvidia.com/edm/pretrained/edm-ffhq-64x64-uncond-vp.pkl with:

mkdir ./pretrained/
wget https://nvlabs-fi-cdn.nvidia.com/edm/pretrained/edm-ffhq-64x64-uncond-vp.pkl ./pretrained/

Train model of CLIP embeddings (called auxiliary model in paper)

Run on 1 GPU:

torchrun --standalone --nproc_per_node=1 train.py --path=datasets/ffhq-64x64.zip --data_class CLIPDataset --batch 256 --seed 1 --exist 0,1 --observed 0,0 --arch=dalle2 --lr=1e-4 --augment=0.15 --pred_x0 1

Train model of images given CLIP, finetuned from EDM's unconditional model (called conditional image model in paper):

Run on 4 GPUs (see the torchrun documentation for help with parallel training):

torchrun --standalone --nproc_per_node=4 train.py --path=datasets/ffhq-64x64.zip --data_class CLIPDataset --batch 128 --seed 1 --exist 1,1 --observed 0,1 --arch=ddpmpp --cres=1,2,2,2 --lr=1e-4 --dropout=0.05 --augment=0.15 --pretrained_weights pretrained/edm-ffhq-64x64-uncond-vp.pkl

Sampling and evaluating trained models

After training a model, you can find the saved checkpoint at the path training-runs/<WANDB ID>/network-snapshot-<KIMG>.pkl, where <WANDB ID> is a randomly-generated identifier used by the run and its logs on Weights & Biases and <KIMG> is the training progress, measured by how many thousands of training images have been seen. We sample from VCDM by first sampling CLIP embeddings with

torchrun --standalone --nproc_per_node=1 generate.py --seeds=0-19999 --batch=64 --network=training-runs/<AUXILIARY MODEL WANDB ID>/network-snapshot-<AUXILIARY MODEL KIMG>.pkl --steps 40 --S_churn 50 --S_noise 1.007

This samples CLIP embeddings and saves them to results/<AUXILIARY MODEL WANDB ID>/network-snapshot-<AUXILIARY MODEL KIMG>/S_churn-50.0_S_max-inf_S_min-0.0_S_noise-1.007_class-None_discretization-None_num_steps-40_rho-7.0_scaling-None_schedule-None_sigma_max-None_sigma_min-None_solver-None/samples-0-19999/. We then generate images given these CLIP embeddings with:

torchrun --standalone --nproc_per_node=1 generate.py --seeds=0-19999 --batch=64 --network=training-runs/<CONDITIONAL IMAGE MODEL WANDB ID>/network-snapshot-<CONDITIONAL IMAGE MODEL KIMG>.pkl --steps 40 --S_churn 50 --S_noise 1.007 --load_obs_from results/<AUXILIARY MODEL WANDB ID>/network-snapshot-<AUXILIARY MODEL KIMG>/S_churn-50.0_S_max-inf_S_min-0.0_S_noise-1.007_class-None_discretization-None_num_steps-40_rho-7.0_scaling-None_schedule-None_sigma_max-None_sigma_min-None_solver-None/samples-0-19999/

The images will be saved to results/<CONDITIONAL IMAGE MODEL WANDB ID>/network-snapshot-<CONDITIONAL IMAGE MODEL KIMG>/S_churn-50.0_S_max-inf_S_min-0.0_S_noise-1.007_class-None_discretization-None_num_steps-40_rho-7.0_scaling-None_schedule-None_sigma_max-None_sigma_min-None_solver-None/results_<CONDITIONAL IMAGE MODEL WANDB ID>_network-snapshot-<AUXILIARY MODEL KIMG>_S_churn-50.0_S_max-inf_S_min-0.0_S_noise-1.007_class-None_discretization-None_num_steps-40_rho-7.0_scaling-None_schedule-None_sigma_max-None_sigma_min-None_solver-None_samples-0-19999/samples-0-19999.

For evaluation, we use the fid.py script similarly to how it is described in the EDM repo. E.g., for FFHQ, we download https://nvlabs-fi-cdn.nvidia.com/edm/fid-refs/ffhq-64x64.npz to ./fid-refs/ and then run

torchrun --standalone --nproc_per_node=1 fid.py calc --images=<SAMPLED IMAGES DIR> --ref=fid-refs/ffhq-64x64.npz --num 20000

Results directory structure

Following this repo, we sampled images and CLIP embeddings are saved with the following directory structure:

results
├── <wandb_id>
│   ├── <checkpoint_name>
│   │   ├── <sample_args>
│   │   │   ├── samples-[n1]-[n2]
│   │   │   │  ├── [n1].png
│   │   │   │  ├── ...
│   │   │   │  └── [n2].png
│   │   │   ├── samples-[n3]-[n4]
│   │   │   │  └── ...
│   │   │   └── ...
│   │   └── ... (samples from same checkpoint with different sampler arguments)
│   └── ... (other checkpoints of the same run)
└── ... (other wandb runs)

Citation

@article{harvey2023visual,
  title={Visual Chain-of-Thought Diffusion Models},
  author={Harvey, William and Wood, Frank},
  journal={arXiv preprint arXiv:2303.16187},
  year={2023}
}
